光學參數 @25℃ |
型號 |
||||||
|
CBO25 |
CBO27 |
CBO30 |
CBO33 |
CBO37 |
CBO40 |
CBO42 |
|
|
操作模式 |
CW |
||||||
|
偏振態 |
隨機(SM)或線性 (PM 且 PER>20dB) |
隨機(SM) 或線性(PM 且PER>17dB) |
|||||
|
輸出功率 (@最小輸入) |
25dBm |
27dBm |
30dBm |
33dBm |
37dBm |
40dBm |
42dBm |
|
波長范圍 |
1540-1565nm |
1545-1565nm |
|||||
|
輸入功率范圍 |
5 to 15dBm |
10 to 20dBm |
15 to 25dBm |
||||
|
輸入監測 |
有 |
||||||
|
輸出監測 |
有 |
有 (可選) |
|||||
|
工作模式 |
ACC，APC |
ACC，APC (可選) |
|||||
|
APC調節范圍 |
10 to 100% |
||||||
|
功率穩定度(rms over 1hr) |
<1% |
<2% |
|||||
|
窄線寬(<100kHz)放大 |
是 |
是(可選) |
|||||
|
端口連接方式 |
SMF28 or PANDA |
||||||
|
輸入 / 輸出終端 |
FC/APC，SC/APC FC/SPC，SC/SPC |
FC/APC，SC/APC，E2PS，C1 |
|||||
|
功耗 |
15W |
20W |
30W |
50W |
100W |
150W |
200W |
|
應用平臺 |
B202，M102，M301 |
B202 |
B203，M403 |
B301 |
|||
